500 - 7000CD Brightness Outdoor Rental Led Screen SMD P3.91 1R1G1B Customize Pixel
Product Details:
| Place of Origin: | China |
| Brand Name: | TOPLED |
| Certification: | CE ROSH FCC |
| Model Number: | P1.25-P10 available |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Woden case/Carton box/Flight case |
| Delivery Time: | 10-25 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 per month |
|
Detail Information |
|||
| Pixel Pitch(mm): | P1.25-P10 Available | Physical Density(dot/sqm): | 10000-640,000 |
|---|---|---|---|
| LED Configuration: | 1R1G1B | Module Size(mm): | Customize |
| Brightness(CD/sqm): | 500-7000CD | Grey Scale: | 14-16bit |
| Refresh Rate(HZ): | 1920/2880/3840HZ | Panel Resolution: | Customize |
| Highlight: | led display on rent,outdoor rental led screen |
||
Product Description
500 - 7000CD Brightness Outdoor Rental Led Screen SMD P3.91 1R1G1B Customize Pixel
Technical Parameter | |||
Pixel pitch | 3.91 mm | Cabinet type | aluminium-magnesium alloy cabinet |
Pixel configuration | 1RGB | LED cabinet resolution | 128*128 |
LED type | SMD 1919 (Pure Black light) | LED cabinet dimension | 500*85*500 mm |
LED chip | KN Light | LED cabinet weight | 7kg |
LED module size | 250*250mm | LED cabinet area | 0.25m2 |
LED module resolution | 65*65 | Ingress Protection | Ip65 |
Pixels per sqm. | 65,536 | Serviceability | Front service |
LEDs qty. per sqm. | 65,536 | Storage environment | Temperature: -40℃ ~ 60℃ |
Display refresh rate | 3840HZ | Operating environment | Temperature: -20℃ ~ 50℃ |
Scan mode | 16scan | Source compatibility | CVBS, YC, YUV, RGB, DVI, SDI, HD-SDI, HDMI |
Driving IC | ICN2015+2012 | Maximal power/per cabinet | 200-300W |
Brightness | 800-3000CD | Average power/per cabinet | 67-100W |
Delivery in 10-25 working days after got deposit.
