Durable Led Backdrop Screen , P25 Programmable Led Curtain Auto Heat Dissipation
Product Details:
| Place of Origin: | China (Mainland) |
| Brand Name: | Singheng |
| Certification: | CE RoHS UL FCC |
| Model Number: | P25 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | USD+To be negotiated+square meter |
| Packaging Details: | Plywood case |
| Delivery Time: | About 16 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000+square meter+per month |
|
Detail Information |
|||
| Brightness: | ≥8000cd/sqm | Max Power Consumption: | 960w/sqm |
|---|---|---|---|
| Average Power Consumption: | 350w/sqm | Pitch Pixel: | 25 Mm |
| Module Size: | 256*128 Mm | Module Resolution: | 12*6 Dot |
| Pixel Configuration: | 1R1G1B DIP346 | LED Brand: | EPISTAR |
| Refresh Rate: | >1920Hz | Grey Scale: | 65536 |
| Highlight: | led curtain wall display,led video curtain |
||
Product Description
Led Curtain Screen Price Outdoor Led Mesh Curtain P25 Led Mesh Display
- Product Description
1. Inner fixed reinforcement plate, tensile and shockproof, auto heat dissipation, make the operating life 10 years.
2. Accurate, shortcut, flexile installation, can be applied to any different installation environment.
3. Due to the light weight and low power consumption, it can reduces the labor cost,operating cost and transportation cost.
4. Outdoor Led mesh curtain breaks through the limitation of conventional LED display to the building and wall ,making the project more flexible and more selective.
5. Led curtain screen is suitable for the construction of super large outdoor display, which is the first choice for creating landmark dynamic display landscape.
6. Also known as LED light bar screen, LED grid screen, LED glass curtain wall display, LED strip screen, LED shaped screen.
- Technical parameters of P25 Led Mesh Display
| Item | Product parameter |
| Pixel Pitch | 25mm |
| Pixel Density | 1600 dots/sqm |
| Pixel configuration | 1R1G1B DIP346 |
| Module Size | 256*128 mm |
| LED brand | Taiwai EPISTAR |
| Cabinet type | Open |
| Module Resolution | 12*6dot |
| Weight | 25KG/sqm |
| Viewing Distance | ≥25m |
| Viewing Angle (Horizontal Axis) | 120° |
| Viewing Angle (Vertical Axis) | 80° |
| Refresh Rate | >1920Hz |
| Grey Scale | 65536 |
| Brightness | ≥8000cd/sqm |
| Max Power Consumption | 960w/sqm |
| Average Power Consumption | 350w/sqm |
| Drive Mode | Static Scan |
| Signal EMC | VGA,DIV,HDMI,SDI |
| Lifespan | ≥10,0000 h |
| Waterproof Grade | IP65 |
| Input Voltage | AC105-235V 50-60HZ |
| Celsius | -40℃-40℃ |
| humidity | 10—85%RH |
| Control Distance | Network Cable≤100m, Multimode optical fiber≤500m, Single mode optical≤20 kilometer |
- FAQ
Q1: LED display models are generally expressed in PX, such as P2 P3 P4....P8 P10.What does this mean?
A: P2 P3 P4.....P8 P10 means the pixel pitch is 2mm 3mm 4mm....8mm 10mm,which determines the number of pixels per unit area of a display. So it represents the clarity of the display. The smaller the pitch, the higher the clarity. Usually, the models of indoor full color display are P1.875,P2.5,P3,P4,P5. Outdoor full color display are P4,P5,P6,P8,P10.
Q2: To order a display, what information should l offer you?
A: You should provide width and height of the display, the main usage, the viewing distance, the scene photo and special requirements, then I can provide you a quotation. Sometimes you should also provide information such as geographical location, local climate.
Q3: How to install?
A: Free of charge to provide detailed steel structure drawings and installation guidance, wiring diagram and free remote debugging .We can also send our engineers to the site to guide the installation.
Q4: What about the lead time?
A: Orders less than 50 square meters display ,lead time is 16 days.
Q5: Can I order a sample?
A: Yes.We welcome customers to order sample to check the quality and service.
