P20 Ultra Light LED Curtain Screen 8000 Cd/Sqm Brightness HS Code 8528591090
Product Details:
| Place of Origin: | China (Mainland) |
| Brand Name: | Singheng |
| Certification: | CE RoHS UL FCC |
| Model Number: | P20 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | USD+To be negotiated+square meter |
| Packaging Details: | Plywood case |
| Delivery Time: | About 16 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000+square meter+per month |
|
Detail Information |
|||
| Application: | Video | Warranty: | 3 Years |
|---|---|---|---|
| LED Chip: | Epistar | Brightness: | 8000cd/sqm |
| Life Span: | 100000 Hours | HS Code: | 8528591090 |
| Usage: | Outdoor | Screen Dimension: | Customized Size |
| Material: | Aluminum | Grey Scale: | 16.7M Colors |
| Highlight: | led curtain wall display,led video curtain |
||
Product Description
P20 Ultra Light Ultra Thin Full Color Window Screen LED Grille Display
- Product Description
1. Light weight and low wind load. The light weight is due to the screen grid, which makes the LED display transparent, so its wind load capacity is extremely strong.
2. High performance and low power consumption. The real energy saving comes from: high-brightness, high-efficiency LED lights, high conversion efficiency power supplies.
3. Highly integrated. Built-in power supply and receiving card, each unit can work independently; power and signal are plugged in one line
4. IP67 high protection level. The concept of IP67 is soaking and waterproofing, that is, the overall immersion of the product.
5. With the high quality raw material, mature process and scale production,the quality is ensured.
6. The cabinet is light in weight,low installation cost and low power consumption, saving operating costs and reducing labor costs.
7. The brightness is high , can be over 6000 nits or higher , no problem at all even under direct sunlight .
8. All our outdoor LED display screen with high quality,quality is very high . Less dead lamps even used over 2-3 years .It can save much money for maintenance.
- Technical parameters
| Item | Parameter |
| Pixel Pitch | 20 mm |
| Pixel Density | 2500dots/sqm |
| Pixel Configuration | 1R1G1B DIP346 |
| Module Size | 320*160 mm |
| Module Resolution | 16*8 dots |
| Cabinet Resolution | 48*56 dots |
| Cabinet Size | 960*1120 mm |
| Viewing Distance | ≥20 m |
| Viewing Angle (Horizontal Axis) | 120° |
| Viewing Angle (Vertical Axis) | 80° |
| Refresh Rate | >1920Hz |
| Grey Scale | 65536 |
| Brightness | ≥8000cd/sqm |
| Max Power Consumption | 700 w/sqm |
| Average Power Consumption | 2500 w/sqm |
| Drive Mode | static |
| Signal EMC | VGA,DIV,HDMI,SDI |
| Signal Transmission Mode | 568B |
| Network Cable | ≤100m, Multimode |
| Control Distance | optical fiber≤500m, Single mode optical |
| fiber | ≤20 kilometer |
| Lifespan | ≥10,0000 h |
| Waterproof Grade | IP 65 |
| Input Voltage | AC220V±10% 50~60HZ |
| Celsius | Degree:-10℃~40℃ |
| Humidity | 10~85%RH |
- FAQ
Q1: To order a display, what information should l offer you?
A: You should provide width and height of the display, the main usage, the viewing distance, the scene photo and special requirements, then I can provide you a quotation. Sometimes you should also provide information such as geographical location, local climate.
Q2: How to install?
A: Free of charge to provide detailed steel structure drawings and installation guidance, wiring diagram and free remote debugging .We can also send our engineers to the site to guide the installation.
Q3: What about the warranty?
A: Three year warranty
Q4: What about the lead time?
A: Orders less than 50 square meters display ,lead time is 16 days.
Q5: Can I order a sample?
A: Yes.We welcome customers to order sample to check the quality and service.
Q6: Is it OK to print my LOGO on your product?
A: Yes.We support OEM and ODM service.
