HD P5 Outdoor Full Color LED Screen SMD2727 960*960mm Standard Cabinet Size
Product Details:
| Place of Origin: | China (Mainland) |
| Brand Name: | TOPLED |
| Certification: | CE FCC ROHS |
| Model Number: | P5 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Fight case or Standard wooden box |
| Delivery Time: | 10-15 working days after got deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Name: | P5 Led Display Panel HD Full Color LED Display Screens In Wall | Usage: | Outdoor |
|---|---|---|---|
| Pixel Pitch: | 5MM | Material: | Steel/Iron |
| Color: | Full Color | Brightness: | 6500nits |
| LED: | SMD2727 | Warranty: | 2 Years |
| Highlight: | led advertising display screen,full color led message board |
||
Product Description
P5 Led Display Panel HD Full Color LED Display Screens in Wall
Specification:
| Pixel Pitch | 5mm |
| Pixel Density | 40000dots/sq.m |
| Color Configuration | 1R1G1B |
| LED Package | SMD2727 |
| Display | Full Color |
| Module Size | 160mm x 160mm |
| Module Resolution | 32dots x 32dots |
| Drive Duty | 1/8 Scan |
| Standard Cabinet Size | 960*960mm |
| Cabinet Weight | 45kg |
| Led Chip | Nationstar / Kinglight |
| Power | DC 5V, AC110V-220V |
| Brightness | ≥6500 cd/sqm |
| Viewing Distance | 5M |
| Viewing Angle | H: 140°; V:140° |
| Refresh Rate | >1920HZ, adjustable by software |
| Power Input | AC110V/ 220V ±10%, 50HZ |
| Max Power Consumption | 900W/cabinet |
| Ave. Power Consumption | 300W/cabinet |
| Temperature | -40℃~+65℃ |
| MTBF | >10,000 Hours |
| Life Span | >100,000 Hours |
| Waterproof Level | IP65 |
| Operating Humidity | 10%~90% RH |
| Control Method | Synchronous, Asynchronous, |
| Operating System | Win 98, Win2000, XP, Win7, Win8 |
| Certificate | CE, RoHS,ISO9001 |
Pre-sale service.
Reply enquiries in 24 hours. Market research and forecast for customer.Provide unique and professional solutions based on customer's requirement.Data sheet and samples offer.response in time, solve problems as soon as possible. Any problem you can contact us at any time you like.
In-sale service.
Tracking report in producing; Quality test report for every order;photos and videos as per customer's requirement. We can guide on line if customers have questions about the installation and usage. For large project, we also can provide your engineer a week free training, or if customer could bear the relevant cost, our engineer can go to customer’s country for on-site guidance.
After-sale service.
In the Maintenance period, free of all maintenance charges. Under normal use and storage, our company will be responsible for the equipment. If there is any failure in product quality, our company will maintain and change the components for free. After Maintenance period, only charge the material costs fees free of manual work fees.
Application:
