SMD RGB Video Full Color LED Display 48*2 Matrix High Definition P6.67
Product Details:
| Place of Origin: | Shenzhen China |
| Brand Name: | Lecede |
| Certification: | CE ROHS FCC UL ETL |
| Model Number: | Q6.67 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case packing, flight case packing , honeycomb case |
| Delivery Time: | 15~30 days after deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 ㎡/month |
|
Detail Information |
|||
| Product Name: | P6.67 LED Display | Average Life Span: | 100,000 Hours |
|---|---|---|---|
| Pixel Density: | 22477 Dot/sqm | Brightness: | 6000 Nits |
| LED Lamp: | SMD3535 | Power Supply: | AC 110/220V |
| Feature: | Full Color | Refresh Rate: | 1920Hz |
| Highlight: | full color outdoor advertising led display,full color led message board |
||
Product Description
Outside SMD RGB Video Full Color LED Display 48 x 2Matrix High Definition P6.67
Features:
1. Cabinet only weighs 14.5kg, thickness 75mm, saving transportation cost and
labor intensity;
2. Spring locks connect the cabinets vertically, hanging max 15 cabinets in a line;
3. Fast spring locks connect the cabinets horizontally, only 10 seconds for per
cabinet;
4. Macromolecular flexible mask with glareless surface and better contrast ratio;
5. Nanotechnology and unique positioning system, making the installation and
dismantlement in one step;
6. Signal and power indicator & reset button well shows the working condition
of the whole screen;
7. All external cable with quick inserted plug for easy installation and
maintenance;
8. Adopting Silica gel to make the cabinet waterproof and sealed, IP65.
Technology parameters:
| Item | Parameters |
| Pixel Pitch | 6.67mm |
| Pixel Density | 22,477 dots/m2 |
| LED Configuration | 1R,1G,1B |
| Colors | >16.7 M |
| Brightness | >6000 nits |
| Gray Scale | >16 bit |
| Refresh Rate | >1920 Hz |
| Viewing Angle | 140°(Horizontal) |
| 140°(Vertical) | |
| Dimension | 640mm x 640mm x 89mm |
| Resolution | 96 x 96 |
| Weight | 14.5kg |
| Protection Level | IP65 |
| Maximum Hanging | Max 15 panels |
| Input Voltage | AC 110V~220V+/-10% |
| Source | DVI, RGB, CVBS, HDMI, YUV, SDI etc |
| Temperature | -20°C ~ +40°C (operating) |
| -20°C ~ +60°C (storage) | |
| Humidity | 10% ~ 90% (operating) |
| 10% ~ 90% (storage) | |
| Life Span | 100,000 hrs |
Our Services
1. Warranty
(1) We provide warranty of all components for 24 months. During this time, we will replace or repair our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materials only.
2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consultation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, RoHS and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional Service
We provide you the forwarding information, and some other information such as flight case, structure information for your reference for free.
