HD SMD Small Led Display Board , Small Pitch Led Display P1.25 P1.5625 1R1G1B
Product Details:
| Place of Origin: | China |
| Brand Name: | TOPLED |
| Certification: | CE ROSH FCC |
| Model Number: | P1.25 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Woden case/Carton box/Flight case |
| Delivery Time: | 10-25 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 per month |
|
Detail Information |
|||
| Pixel Pitch(mm): | P1.25-P10 Available | LED Configuration: | 1R1G1B |
|---|---|---|---|
| Module Size(mm): | Customize | Module Resolution: | Customize Pixel |
| Grey Scale: | 14-16bit | Refresh Rate(HZ): | 1920/2880/3840HZ |
| Panel Size(mm): | Customize | Panel Resolution: | Customize |
| Panel Power Consumption(W): | 200-750W | ||
| Highlight: | small pixel led display,hd led display |
||
Product Description
High definition HD SMD P1.25 P1.5625 P1.667 P1.875 full color indoor LED Display modules P1.25
Specification
|
Item
|
Technical parameter
|
||
|
Panel
|
Dimension
|
(W)200mm*150mm(H)
|
|
|
Pixel pitch
|
1.25mm
|
||
|
Pixel configuration
|
1R1G1B
|
||
|
LED specification
|
SMD1010
|
||
|
Pixel resolution
|
(W)160*120(H)
|
||
|
Average power
|
25W
|
||
|
Panel weigth
|
0.35
|
||
|
Cabinet
|
Dimension
|
400*300*85mm
|
|
|
Quantity of panel
|
4PCS
|
||
|
Working temperature
|
-20--+60
|
||
|
Best viewing distance
|
1-30M
|
||
|
Best viewing angle
|
170/120
|
||
|
Panel power supply
|
5V60A
|
||
|
Screen power supply
|
220VAC/50Hz+_10%
|
||
|
Max power
|
1250W/sqm
|
||
|
Average power
|
500W/sqm
|
||
|
Technical parameter
|
Driving device
|
2053Constant current drive
|
|
|
Drive type
|
1/20S
|
||
|
Refresh frequency
|
2880HZ/S
|
||
|
Display color
|
4096*4096*4096
|
||
|
Brightness
|
400-800mcd/sqm
|
||
|
Life span
|
100000Hours
|
||
|
Communication distance
|
<100M
|
||
Lead Time:Delivery in 10-25 working days.
