P6.67 Advertising LED Display 22500dots/㎡ Pixel With Large Viewing Angle
Product Details:
| Place of Origin: | Shenzhen China |
| Brand Name: | Lecede |
| Certification: | CE ROHS FCC UL ETL |
| Model Number: | Q6.67 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case packing, flight case packing , honeycomb case |
| Delivery Time: | 15~30 days after deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 ㎡/month |
|
Detail Information |
|||
| Product Name: | Lecede P6.67 Advertising LED Display Screen | Pixel Pitch: | 6.67MM |
|---|---|---|---|
| Usage: | Outdoor | Pixel: | 22500 Dots/㎡ |
| Module Size(W*H): | 320x 160 Mm | LED Lamp: | SMD 2727 |
| Brightness: | 6500 Nits | Refresh Rate: | ≥1920 Hz |
| Highlight: | digital advertising display screens,led advertising panel |
||
Product Description
P6.67 Advertising LED Display Screen With Large Viewing Angle
1. With good lightening accordance and no mosaic
2. Led advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV,
video signal from video and other equipment
3. Different video frequency can be changed freely at the same time, and the image can be enlarged and
reduced
4. High brightness, and can be adjustable, meets the need of changing requirement of customer in
environment
SPECIFICATION OF Q6.67 Outdoor Advertising LED Display Screen
| Model | Q6.67 |
| Pixel pitch(mm) | 6.67 |
| Configuration | SMD 2727 |
| Module dimension(mm) | 320x160 |
| Module weight(kg) | 0.5 |
| Cabinet dimension(mm) | 960x960x120 |
| Pixel density(dots/㎡) | 22500 |
| Flatness error(mm) | ≤0.1 |
| Viewing angle | 140°/140°(Horizontal/Vertical) |
| Brightness(cd/㎡) | 6500 |
| Color temperature(K) | 5000~9500 (Adjustable) |
| Contrast | 4000:1 |
| Repetition frequency | 50/60Hz |
| Refresh frequency(Hz) | 1920 |
| Gray scale | 65536 |
| Ave. power(W/㎡) | 350 |
| Max power(W/㎡) | 700 |
| Working temp./humidity | -10~40℃/10%~80%RH |
| Storing temp./humidity | -20~60℃/10%~85%RH |
| Cabinet material | Iron/Aluminum |
| Maintenance | Rear |
| Protection | IP65/IP65 |
| Driving mode | Constant current driver |
| Scanning | 1/6 |
| Power requirements | AC90~264V, 47~63Hz |
| Life time(hrs) | 100,000 |
Advantages Of Outdoor Advertising LED Display Screen
1. has high refresh rate, high brightness and high contrast which make the screen with no
delay and smear phenomenon in direct sunlight.
2. energy saving: low electric current, high-bright lamps, equipped with PFC switching
power supply that save 30% electricity.
3. has Wide viewing angle: The horizontal and vertical viewing angles are so wide that it is
suitable for wide horizontal.
