High Definition P5 LED Display Module Full Color -40℃ To 65℃ Working Temperature
Product Details:
| Place of Origin: | China (Mainland) |
| Brand Name: | TOPLED |
| Certification: | CE FCC ROHS |
| Model Number: | P5 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Fight case or Standard wooden box |
| Delivery Time: | 10-15 working days after got deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| LED Encapsulation: | SMD | Usage: | Outdoor |
|---|---|---|---|
| Color: | Full Color | Module Size: | 160mm*160mm |
| Module Resolution: | 32x32dots | Brightness: | 6500cd |
| Product Name: | P5 Led Display Module | Scan: | 1/8scan |
| Highlight: | led screen module,waterproof led module |
||
Product Description
2019 high definition p5 outdoor full color video 160x160 LED display screen module
Features
1. Ultra bright LED lamp, and the best raw materials to made into plastic parts.
2. Chip encapsulation uses pure golden wire to solder, red chip encapsulation uses double pure golden wires to keep stability.
3. The copper silvering trestle.
4. High-end specialized outdoor glue.
5. Brushing black lamp with five surface and black gluing to keep the uniformity of screen.
6. Plated signal and power connector.
7. Pure-copper environmental flat cable,pure-copper power wire.
Parameters
| Pixel Pitch | mm |
| Pixel Density | 40000dots/sq.m |
| Color Configuration | 1R1G1B |
| LED Package | SMD |
| Display | Full Color |
| Module Size | 160mm x 160mm |
| Module Resolution | 32dots x 32dots |
| Drive Duty | 1/8 Scan |
| Power | DC 5V, AC110V-220V |
| Brightness | ≥6500 cd/sqm |
| Refresh Rate | >1920HZ, adjustable by software |
| Power Input | AC110V/ 220V |
| Max Power Consumption | 800W/cabinet |
| Ave. Power Consumption | 300W/cabinet |
| Temperature | -40℃~+65℃ |
| MTBF | >10,000 Hours |
| Life Span | >100,000 Hours |
| Control Method | Synchronous, Asynchronous, 3G,WIFI,USB |
| Certificate | CE, RoHS,ISO9001 |
Reference Module
1. High refresh rate for better picture quality
It uses over 1500Hz refresh rate that produces great quality,flicker free pictures without scan lines.
Delicate pictures can be delivered with great accuracy.
2. High Gray Scale--Better Picture
Outdoor LED Screen is manufactured by using best quality material ,purchased from most reputed vendors .
The final products feature supreme quality and offers best outputs. HIgh refresh rate and gray scale
ensures the picture quality remains seamless
3. Silence Operation --Low Power Consumption
Outdoor LED Screen is known for its silence operation and low power consumption .It is also known for fast heat dissipation which will save more energy .Cut on the electricity expenses and help environment with this highly advanced advertising display.
