Bright Color P8 Outdoor Led Module , Led Screen Module IP65 Degree Protective
Product Details:
| Place of Origin: | China (Mainland) |
| Brand Name: | TOPLED |
| Certification: | CE FCC ROHS |
| Model Number: | P8 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Fight case or Standard wooden box |
| Delivery Time: | 10-15 working days after got deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Usage: | Outdoor | Pixel Pitch: | 8MM |
|---|---|---|---|
| Module Size: | 256*128mm | Brightness: | 6800nits |
| Scan: | 1/4 Scan | Warranty: | 2 Years |
| Highlight: | led panel module,waterproof led module |
||
Product Description
Outdoor p8 energy-saving advertising led display module led display with good price
Features:
1. Bright color, high contrast, good consistency and high brightness to keep the high resolution of the video under the sunlight.
2. CNC Technology for cabinet, flatness between cabinet units<0.2mm.
3. Red led were powered by 3.2V, blue and green LEDs were powered by 3.8V, which make the screen work stable and prolong the life span
4. With PFC high-efficiency power supply, to ensure the screen can be Powered sustainable.
Specification:
| Pixel Pitch | 8mm |
| Pixel Density | 15625dots/sq.m |
| Color Configuration | 1R1G1B |
| LED Package | SMD3535 |
| Display | Full Color |
| Module Size | 256mm x 128mm |
| Module Resolution | 32dots x 16dots |
| Drive Duty | 1/4 Scan |
| Standard Cabinet Size | 1024*1024mm |
| Cabinet Weight | 45kg |
| Led Chip | Nationstar / Kinglight |
| Power | DC 5V, AC110V-220V |
| Brightness | ≥6800 cd/sqm |
| Viewing Distance | 8M |
| Viewing Angle | H: 140°; V:140° |
| Refresh Rate | >1920HZ, adjustable by software |
| Power Input | AC110V/ 220V ±10%, 50HZ |
| Max Power Consumption | 800W/cabinet |
| Ave. Power Consumption | 280W/cabinet |
| Temperature | -40℃~+65℃ |
| MTBF | >10,000 Hours |
| Life Span | >100,000 Hours |
| Waterproof Level | IP65 |
| Operating Humidity | 10%~90% RH |
| Control Method | Synchronous, Asynchronous, |
| Operating System | Win 98, Win2000, XP, Win7, Win8 |
| Video Signal Mode | RF, S-Video, RGB, RGBHV, YUV, YC etc |
| Certificate | CE, RoHS,ISO9001 |
Application:
outdoor advertisong led video screen can be placed anywhere, such as: building surface, roof, highway, roadside, commercial center, etc;
