1R1G1B P2.5 SMD Led Display Screen , Indoor Full Color LED Screen ROHS
Product Details:
| Place of Origin: | Shenzhen China |
| Brand Name: | Lecede |
| Certification: | CE ROHS FCC UL ETL |
| Model Number: | HD2.5 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case packing, flight case packing , honeycomb case |
| Delivery Time: | 15~30 days after deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 ㎡/month |
|
Detail Information |
|||
| Product Name: | 1R1G1B Full Color P2.5 Front Service LED Display Indoor LED Screen | Pixel Pitch (MM): | 2.5 |
|---|---|---|---|
| Usage: | Intdoor Front Service | Pixel: | 160000 Dots/㎡ |
| Module Size(W*H): | 3200x 160 Mm | LED Lamp: | SMD 1515 Lamp |
| Brightness: | 900 Nits | Refresh Rate: | 1920 Hz |
| Highlight: | smd led display screen,led rental display |
||
Product Description
1R1G1B Full Color P2.5 Front Service LED Display Indoor LED Screen
Product Features
1. Ultra-wide viewing angle.
2. High refresh rate
3. Seamless splicing between the cabinets
4. Noiseless Design
5. Ultra-high resolution display
SPECIFICATION OF HD2.5 Indoor Front Service LED Display
| Model | HD2.5 |
| Pixel pitch(mm) | 2.5mm |
| LED Configuration | SMD 1515 lamp |
| Module size(mm) | 320 x 160mm |
| Module weight(kg) | 0.9 |
| Cabinet size(mm) | Customized |
| Pixel density(dots/㎡) | 160000 dots |
| Flatness error(mm) | ≤0.2 |
| Viewing angle | 160°/160°(Horizontal/Vertical) |
| Brightness(cd/㎡) | 7400 nits |
| Color temperature(K) | 5000~9500 (Adjustable) |
| Contrast | 5000:1 |
| Repetition frequency | 50/60Hz |
| Refresh frequency(Hz) | ≥1920 Hz |
| Gray scale | 16bit |
| Ave. power(W/㎡) | 600 |
| Max power(W/㎡) | 300 |
| Working temp./humidity | -10~40℃/10%~80%RH |
| Storing temp./humidity | -20~60℃/10%~85%RH |
| Cabinet material | Diecast aluminum |
| Maintenance | Front and Rear maintenance |
| Protection | IP65 |
| Driving mode | Constant current driver |
| Scanning | 1/32 S |
| Power requirements | AC90~264V |
| Life time(hrs) | 100,000 |
Advantages OF HD2.5 Indoor Front Service LED Display
1. HD2.5 is HD small pitch product, with smart structure, fast and flexible installation, and high-end
configurations, applied to various sites.
2. Light and slim design: Cabinet is very light and thin, only with 8.5Kg/pcs; fashion die-cast aluminum
design, with 80mm thickness.
3. High quality CNC die-cast aluminum cabinet: Cabinet adopts CNC fine processing to make dimensional
tolerance less than 0.1mm.
4. Seamless connection: Cabinet adopts unique fast locks, connection tightness can be adjustable,
showing perfect visual effects. Cabinet mold is one-time forming with precision ± 0.1mm, very easy to
achieve seamless connection.
5. Front maintenance design: Each module can be maintained from cabinet front side, much quicker and
easier. Also front maintenance is 5 times faster than traditional rear maintenance products, shortening
the maintenance time for users.
6. Buckle mask design: Mask adopts modular buckle design which improves mask flatness and display
effect dramatically.
7. Low brightness and high contrast ratio: This technology works more in line with the small pitch HD LED
displays, instead of the traditional DLP, LCD splicing or projection display applications.
Application of HD2.5 Indoor Front Service LED Display
Ideal for auditorium, conference room, banquet hall and exhibition presentations, traffic, studio, command
and monitor system
