Stage Rental Indoor Led Advertising Screen Solution P3 200 - 800W Panel Power Consumption
Product Details:
| Place of Origin: | China |
| Brand Name: | TOPLED |
| Certification: | CE ROSH FCC |
| Model Number: | P1.25-P10 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Woden case/Carton box/Flight case |
| Delivery Time: | 10-25 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 per month |
|
Detail Information |
|||
| Pixel Pitch(mm): | P1.25-P10 Available | LED Configuration: | 1R1G1B |
|---|---|---|---|
| Module Size(mm): | Customize | Module Resolution: | Customize Pixel |
| Grey Scale: | 14-16bit | Refresh Rate(HZ): | 1920/2880/3840HZ |
| Panel Size(mm): | Customize | Panel Resolution: | Customize |
| Panel Power Consumption(W): | 200-800W | Display Function: | Video |
| Highlight: | flexible led display,led wall panels |
||
Product Description
Stage Rental Indoor Led Advertising Screen Solution P3 200 - 800W Panel Power Consumption
Key Specifications/Special Features:
Product: P3 indoor full color
Module size: 192*192mm
LED brand:DSBJ
Pixel density: 111111 dots/m²
LED lamp: SMD2121
Module resolution: 64*64
Module consumption: 25W/pieces
Viewing distance: 3-25M
Max power consumption: 700W/m²
Standard cabinet size: 576*576mm
Drive mode: 1/32scan
Brightness: 800cd/m²
HUB mode: HUB75
Drive IC: MBI5124
Frame frequency: ≧60Hz/s
Refresh rate:360-1920Hz/s
MTTF: >5000 hours
Life time: >100,000 hours
Defect rate: <0.0001
Video signal input: RF, S-Video, RGB, RGBHV, YUV, YC, composition
Temperature range:
Storage: -20-65°C
Working: -20 to 50°C
Gray scale/color: 4096 grades for R, G and B
Display: ≥16.7m colors
Working voltage: 110/220V/AC
Viewing angle:
Horizontal: 120º
Vertical: 120º
Module size: 192*192mm
LED brand:DSBJ
Pixel density: 111111 dots/m²
LED lamp: SMD2121
Module resolution: 64*64
Module consumption: 25W/pieces
Viewing distance: 3-25M
Max power consumption: 700W/m²
Standard cabinet size: 576*576mm
Drive mode: 1/32scan
Brightness: 800cd/m²
HUB mode: HUB75
Drive IC: MBI5124
Frame frequency: ≧60Hz/s
Refresh rate:360-1920Hz/s
MTTF: >5000 hours
Life time: >100,000 hours
Defect rate: <0.0001
Video signal input: RF, S-Video, RGB, RGBHV, YUV, YC, composition
Temperature range:
Storage: -20-65°C
Working: -20 to 50°C
Gray scale/color: 4096 grades for R, G and B
Display: ≥16.7m colors
Working voltage: 110/220V/AC
Viewing angle:
Horizontal: 120º
Vertical: 120º
Lead Time:Delivery in 10-25 working days.
Want to Know more details about this product
