1/16 Scan Drive Duty Indoor LED Video Wall 3.9mm Pitch 1R1G1B Color Configuration
Product Details:
| Place of Origin: | China (Mainland) |
| Brand Name: | TOPLED |
| Certification: | CE FCC ROHS |
| Model Number: | P3.91 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Fight case or Standard wooden box |
| Delivery Time: | 10-15 working days after got deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Name: | Best Price Quality Event Rental Fullcolor Indoor Led Video Wall Screen | Usage: | Indoor |
|---|---|---|---|
| Cabinet Size: | 500*500mm | Material: | Die Casting Aluminum |
| Module Size: | 250*250mm | Brightness: | 1000nits |
| Pitch: | 3.9mm | Scan: | 16scan |
| Highlight: | flexible led display,led video wall display |
||
Product Description
Best Price Quality Event Rental Fullcolor Indoor Led Video Wall Screen
Specification:
| Pixel Pitch | 3.91mm |
| Pixel Density | 65536dots/sq.m |
| Color Configuration | 1R1G1B |
| LED Package | SMD2121 |
| Display | Full Color |
| Module Size | 250mmx 250mm |
| Module Resolution | 64dots x 64dots |
| Drive Duty | 1/16 Scan |
| Standard Cabinet Size | 500*500mm |
| Cabinet Weight | 6kg |
| Led Chip | Nationstar / Kinglight |
| Power | DC 5V, AC110V-220V |
| Brightness | ≥1000 cd/sqm |
| Viewing Distance | 3.91M |
| Viewing Angle | H: 140°; V:140° |
| Refresh Rate | >3840HZ, adjustable by software |
| Power Input | AC110V/ 220V ±10%, 50HZ |
| Max Power Consumption | 100W/cabinet |
| Ave. Power Consumption | 30W/cabinet |
| Temperature | -40℃~+60℃ |
| MTBF | >10,000 Hours |
| Life Span | >100,000 Hours |
| Operating Humidity | 10%~90% RH |
| Control Method | Synchronous, Asynchronous, 3G,WIFI,USB |
| Control PC | With DVI Graphic card |
| Certificate | CE, RoHS,ISO9001 |
videos and texts
1. Excellent design should be easy to understood, the product will talk for itself, cancelling the necessity of detailed explain.
2. Seamless stitching: With our special connector design it is easy to reduce gaps while installing, creating a perfect display.
3. Adopt the latest anti-collision technology, make a more stable cabinet during rental events, make a longer life span.
4. Magnesium aluminum alloy control box, adapt to all kinds of weather.
5. Customized Arc design: bevel edge cabinet design according to customer requirements makes Arc screen assembling.
6. Gapless connection: under 0.1 mm tolerance gap between cabinet and module, under 0.2mm tolerance gap between cabinets.
