High Definition Indoor LED Video Wall Sign Screen Trailer P2.5 1200W/M² SMD2121
Product Details:
Place of Origin: | China |
Brand Name: | TOPLED |
Certification: | CE ROSH FCC |
Model Number: | P1.25-P10 |
Document: | Product Brochure PDF |
Payment & Shipping Terms:
Minimum Order Quantity: | 2 |
---|---|
Price: | Negotiate |
Packaging Details: | Woden case/Carton box/Flight case |
Delivery Time: | 10-25 days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 50000 per month |
Detail Information |
|||
Pixel Pitch(mm): | P1.25-P10 Available | LED Configuration: | 1R1G1B |
---|---|---|---|
Module Size(mm): | Customize | Grey Scale: | 14-16bit |
Refresh Rate(HZ): | 1920/2880/3840HZ | Panel Size(mm): | Customize |
Panel Resolution: | Customize | Display Function: | Video |
Highlight: | flexible led display,led wall panels |
Product Description
LED Sign Screen Trailer High Definition P2.5 Indoor LED Video Screen, PH2.5 LED Panel led video wall curtain
Key Specifications/Special Features:
Product: P2.5 indoor full color
Module size: 160*160mm
Pixel density: 160,000 dots/m²
LED lamp: SMD2121
Module resolution: 64*64
Module consumption: 30W/piece
Viewing distance: 3-15m
Max power consumption: 1200W/m²
Standard cabinet size: 480*480mm
Drive mode: 1/32 scan
Brightness: 1200-1500cd/m²
Hub mode: hub75
Drive IC: FM5020
Frame frequency: ≧60Hz/s
Refresh rate: ≧960Hz/s
MTTF: >5000 hours
Life time: >100,000 hours
Defect rate: <0.0001
Video signal input: RF, S-video, RGB, RGBHV, YUV, YC, composition
Temperature range:
Storage: -20 to 65°C
Working: -20 to 50°C
Gray scale/color: 4096 grades for R ,G and B
Display: ≥16.7m colors
Working voltage: 110/220V AC
Viewing angle:
Horizontal: 120º
Vertical: 120º
Display content: videos, pictures and graphics
Operating humidity: 10-95%
Storage humidity: 10-95%
Continue working time: 24 hours
Control mode: asynchronization/synchronization
Module size: 160*160mm
Pixel density: 160,000 dots/m²
LED lamp: SMD2121
Module resolution: 64*64
Module consumption: 30W/piece
Viewing distance: 3-15m
Max power consumption: 1200W/m²
Standard cabinet size: 480*480mm
Drive mode: 1/32 scan
Brightness: 1200-1500cd/m²
Hub mode: hub75
Drive IC: FM5020
Frame frequency: ≧60Hz/s
Refresh rate: ≧960Hz/s
MTTF: >5000 hours
Life time: >100,000 hours
Defect rate: <0.0001
Video signal input: RF, S-video, RGB, RGBHV, YUV, YC, composition
Temperature range:
Storage: -20 to 65°C
Working: -20 to 50°C
Gray scale/color: 4096 grades for R ,G and B
Display: ≥16.7m colors
Working voltage: 110/220V AC
Viewing angle:
Horizontal: 120º
Vertical: 120º
Display content: videos, pictures and graphics
Operating humidity: 10-95%
Storage humidity: 10-95%
Continue working time: 24 hours
Control mode: asynchronization/synchronization
Lead Time:Delivery in 10-25 working days.
