• P4 Full Color Indoor Led Display Screen 128*128mm Module Size CE Compliant
P4 Full Color Indoor Led Display Screen 128*128mm Module Size CE Compliant

P4 Full Color Indoor Led Display Screen 128*128mm Module Size CE Compliant

Product Details:

Place of Origin: Guangdong
Brand Name: TOPLED
Certification: CE, ROHS, FCC, ISO9001, ISO14001
Model Number: Indoor p4
Document: Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Wooden case, flight case, honeycomb.
Delivery Time: 15-20 Working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 SQM/Month
Get Best Price Contact Now

Detail Information

Pixel Pitch: 4mm Brightness: 1000cd/sqm
Module Size: 128*128mm Cabinet Size: 512*512mm
Warranty: 2 Years Scan Mode: 1/16
Highlight:

flexible led display

,

led wall panels

Product Description



1/16s P4 Indoor Full Color LED Video Wall with 128mm*128mm Module





Product Description



Features



1. Gorgeous Picture: Non-reflective screen, which brings better viewing experience.

2. Perfect Image: Our products use special IC for LED which owns high refresh rate and achieves no shadows

3. Light Weight: The body uses aluminum profile stitching weighing 5-8kg, which is light and non- corrosive.

4. Elegant Appearance: We adopt CNC processing technique to produce standard module and cabinet which can easily do seamless assemble.

5. Standard Size: We use professional buckles and standard modular panels which can snap together easily.

6. Easy Setup: Back modules are made easier for connection.

7. Energy-saving: Our products get low energy cost and high efficiency.



Parameters



Name Parameter
Pixel Pitch(mm) 4mm
Physical Density 62,500
LED Configuration 1RGB
LED type SMD2121
Module Size 128×128
Module Resolution 32×32
Module Power Consumption 15W
Driving Mode Constant Current IC
Scanning Mode 1/16
Horizontal Viewing Angle 140
Vertical Viewing Angle 140
Brightness 1500
Grey Scale 16bit
Refresh Rate >3840
Cabinet Resolution 128×128
Cabinet Size 512×512
Cabinet Weight(kg) 15
Cabinet Thickness 75
Cabinet Material Iron/Aluminum
Color >16.7
Input Voltage AC 110V~220V +/-10%
Frame Frequency 50~60
Protection Level IP43
Working Temperature(℃) -40° -+65°
Storage Humidity Range(RH) 10%~90%
Life Span(H) 100,000 hours



Module 128mm*128mm



P4 Full Color Indoor Led Display Screen 128*128mm Module Size CE Compliant 0

P4 Full Color Indoor Led Display Screen 128*128mm Module Size CE Compliant 1



Control System



P4 Full Color Indoor Led Display Screen 128*128mm Module Size CE Compliant 2



Attention

In order to offer you a suitable solution, Please state general info about your project.

1. Pixel pitch or view distance you need.

2. Dimension

3. Location of installation. ( eg, on poles, on wall of building, ect)

4. Purpose. ( what are you going to do with the LED Screen)
