1R1G1B Outdoor Small Pixel Pitch Led Display P10 14 - 16 Bit With 1/2 Scan Method
Product Details:
| Place of Origin: | China |
| Brand Name: | TOPLED |
| Certification: | CE ROSH FCC |
| Model Number: | P1.25-P10 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Woden case/Carton box/Flight case |
| Delivery Time: | 10-25 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 per month |
|
Detail Information |
|||
| Pixel Pitch(mm): | P10 | LED Configuration: | 1R1G1B |
|---|---|---|---|
| Module Resolution: | Customize Pixel | Grey Scale: | 14-16bit |
| Refresh Rate(HZ): | 1920/2880/3840HZ | Panel Size(mm): | 960*960mm |
| Panel Resolution: | 96*96dots | Panel Power Consumption(W): | 780W |
| Highlight: | large led display panels,led display panel |
||
Product Description
High brightness Smd Outdoor Big pixel pitch p10 outdoor led display with 1/2 scan methond
1. Product features
l LED display have good waterproof and anti-humidity when used.
l Stable cabinet, stronger without distortion, anti-rust.
l Synchronously adjust the brightness and color to make the true and exquisite image.
l High contrast, high refresh rate make the image without any delay, trailing smear.
l Compatible to many signal sources such as AV, S-Video, DVI, VGA, YPbPr, HDMI,SDI,DP etc.
l Special wooden box package production protect the whole screen system.
2. Technical specification
| Pixel Pitch | 6mm |
| Pixel composing | 1R1G1B |
| Density | 27,777dots/m2 |
| Module resolution | 32 dots* 16 dots |
| Module size | 192mm * 96mm |
| Standard cabinet size | 576mm*576mm or design |
| Weight per sqm | 35 Kg/sqm |
| Whiteness brightness | 5500-7500 cd/sqm |
| Led package | SMD 3in1 |
| Wave Angle (H) | 140degree(H)/140degree(V) |
| Best view distance | >=6m |
| Working voltage | AC 220v/380v+/-10%50-60Hz |
| Power consumption/ m2 | 420W/sqm |
| Short circuit protection | Yes |
| Refresh | 400 Hz |
| Changing frame frequency | 60 Hz |
| Driving method | Constant driving ,1/4scan |
| Working Environment | Outdoor |
| Working temperature | -40-60centigrade |
| Working Humidity | 10-95% |
| Out of control | 1/10,000 ( scattered) |
| lifetime | 100,000 hours |
Products advantages:
1) product advantage: we have 12 years experience to encapsulate.
2) Price advantage: we have the best competitive price and the same even better quality at the market
3) Performance advantage: Best equality, high consistency ,big viewing angle ,can repair each led lights.
4) Quality advantage: From material to finished product, from design to produce, we control all steps, that’s the guarantee of the quality and reliability.
5) Service advantage: Better service at the same situation, better cooperation at same service!
Cabinet Details
